EssFuse: Chinese high-voltage fuse manufacturers provide high-speed fuses, fuse holders, semiconductor fuses, and automotive fuses
The 610F high voltage fuse is a compact, fast-acting 500V DC fuse link designed for reliable circuit protection in high-voltage DC systems. Built with a high-grade ceramic body and precision fusible element, it delivers stable performance, fast response, and excellent arc extinguishing capability.
Key Specifications
- Model: 610F
- Rated Voltage: 500V DC
- Rated Current: 1A–30A (optional)
- Size: 6×30mm (standard cylindrical)
- Speed: Fast-acting (semiconductor protection grade)
- Breaking Capacity: 20kA @ 500V DC
Core Features
- High voltage resistance: Optimized for 500V DC circuits, widely used in new energy and industrial fields.
- Fast-acting performance: Cuts off short-circuit current within milliseconds to protect semiconductors, IGBTs, and sensitive components.
- Compact standard size: 6×30mm body fits mainstream fuse holders (PCB, panel, inline) for easy replacement.
- Ceramic insulation: High-temperature, explosion-resistant ceramic housing ensures safe operation in harsh environments.
Typical Applications
- New energy vehicles (EV/HEV) low-voltage DC systems
- Solar photovoltaic (PV) combiner boxes and DC distribution
- Industrial power supplies, UPS, and rectifier units
- Semiconductor equipment and control circuits
- Energy storage systems (ESS) and battery packs
Why Choose 610F 500V DC Fuse Link
As a professional high voltage fuse link, the 610F balances size, voltage resistance, and response speed. It is a cost-effective solution for 500V DC protection, widely adopted by equipment manufacturers and system integrators.
