Description
Features & Benefits
Partial Range Protection: Designed specifically for partial range protection needs.
Low I²t: Offers low I²t values and strong current limiting capability.
High Breaking Capacity: Ensures reliable operation under high fault conditions.
Industrial Applications: Suitable for industries like rail transit, electric vehicles, and boats.
Versatile Backup Protection: Provides backup protection after short-circuiting for energy storage systems, power systems, conductors, and other equipment.
Volts: 1000Vdc
Amps: 25A-250A
Interrupting Capacity:
Max: 1000Vdc 50kA (or less)
Min: ≥ 3.0 In
Time Constant: ≤ 2±1 ms
Class Type: aR
Dimensions (mm)
Description
- Design For DC Applications
- Excellent Dc Performance
- Superior cycling capability
- Low Watt Losses
Standards/Approvals
- Refer to UL 248.1 / UL 248.13
- IEC 60269.1 / IEC 60269.4
- Reach declaration available upon request
- RoHS Compliant
Fuse Ratings
| Part No. | Fuse Amps | Breaking Capacity | Average @50KA/1000Vdc | Power Loss (W) | Installation torque | |
| A²s Melting | A²t Clearing | 100% | ||||
| GFEVT1000-25A-36 | 25 | 50kA | 21 | 105 | 8 | 11.0±1.0 N·m |
| GFEVT1000-32A-36 | 32 | 50kA | 38 | 185 | 10 | 11.0±1.0 N·m |
| GFEVT1000-40A-36 | 40 | 50kA | 68 | 325 | 12 | 11.0±1.0 N·m |
| GFEVT1000-50A-36 | 50 | 50kA | 155 | 745 | 16 | 11.0±1.0 N·m |
| GFEVT1000-63A-36 | 63 | 50kA | 305 | 1450 | 20 | 11.0±1.0 N·m |
| GFEVT1000-80A-36 | 80 | 50kA | 560 | 2480 | 22 | 11.0±1.0 N·m |
| GFEVT1000-100A-36 | 100 | 50kA | 960 | 4820 | 25 | 11.0±1.0 N·m |
| GFEVT1000-125A-36 | 125 | 50kA | 1640 | 8950 | 27 | 11.0±1.0 N·m |
| GFEVT1000-160A-36 | 160 | 50kA | 4100 | 18750 | 36 | 11.0±1.0 N·m |
| GFEVT1000-200A-36 | 200 | 50kA | 9560 | 39700 | 39 | 11.0±1.0 N·m |
| GFEVT1000-225A-36 | 225 | 50kA | 11780 | 54700 | 42 | 11.0±1.0 N·m |
| GFEVT1000-250A-36 | 250 | 50kA | 14500 | 70590 | 45 | 11.0±1.0 N·m |
| *: If there are any requirements, please communicate with the original factory staff first. | ||||||
