GF‑718 ATO blade fuse holder clip PCB mount, 40A AC250V
GF‑718 ATO blade fuse holder clip PCB mount, PCB through‑hole soldering type for medium‑size ATO automotive blade fuses, max 40A AC250V, reliable clamping force.
Need a Fuse for Your Project?
Share your requirements with us for product guidance and a quotation.
GF-718-ATO-blade-fuse-holder-clip
GF‑718 ATO blade fuse holder clip PCB mount
GF‑718 ATO blade fuse holder clip PCB mount is a PCB through‑hole soldered fuse clip designed for medium‑size automotive ATO blade fuses. It features stable contact performance and qualified insertion‑extraction force. Suitable for AC250V circuit up to 40A, widely adopted for automotive PCB over‑current and short‑circuit protection. It matches our GF‑B ATO medium blade fuse.
Key Features
- Model: GF‑718 ATO blade fuse holder clip PCB mount
- Compatible Fuse: Medium‑size automotive ATO blade fuses
- Mounting Method: PCB through‑hole soldering installation
- Rated Spec: Max 40A, AC250V
- Initial insertion‑extraction force: 0.5‑2kg
- Contact resistance: ≤20mΩ (before & after durability test)
- Maintain ≥0.5kg insertion force after durability test
- Compact dual‑position layout, save PCB layout space
- Good vibration resistance for automotive electronic environment
Technical Specifications
Rated VoltageInsertion Force After Durability TestInstallation Type
| Product Model | GF‑718 ATO blade fuse holder clip PCB mount |
| Matching Fuse | Medium‑size Automotive ATO Blade Fuse |
| Max Rated Current | 40A |
| AC 250V | |
| Insertion‑Extraction Force (Initial) | 0.5kg‑2kg |
| ≥0.5kg | |
| Contact Resistance (Before / After Test) | ≤20mΩ |
| PCB Through‑hole Mount |
Application Scenarios
GF‑718 ATO blade fuse holder clip PCB mount is widely used for automotive ECU, vehicle lighting control boards, on‑board power modules and other automotive electronic PCBs. It supports quick replacement for medium‑size ATO blade fuses after overload or short‑circuit fault.
Installation Notes
- Through‑hole soldering on PCB; confirm component footprint before PCB layout
- Only compatible with medium‑size ATO blade fuses, not fit MINI / Maxi blade fuses
- Do not exceed rated voltage and current in practical application
- Regular inspection recommended for equipment working under continuous vehicle vibration
Packing & Supply
Bulk packing or tape & reel packing available. Sample testing support, OEM customization and stable mass‑volume supply for automotive electronics manufacturers.
FAQ
Q: Which fuse matches GF‑718 ATO blade fuse holder clip PCB mount?
A: It is designed for medium‑size automotive ATO blade fuses.
Q: What is the maximum current rating of GF‑718?
A: Max 40A under AC250V.
Q: What is insertion‑extraction force for GF‑718?
A: Initial insertion‑extraction force 0.5‑2kg, keeps ≥0.5kg after durability test.
Q: Is GF‑718 PCB mount type?
A: Yes, GF‑718 ATO blade fuse holder clip PCB mount adopts PCB through‑hole soldering installation.
