GFHVT1500‑74ES Series Square‑Body Fast‑Acting aR DC Fuse 1500VDC 100‑800A
GFHVT1500‑74ES square‑body fast‑acting aR DC fuse,1500VDC 100‑800A,50kA breaking capacity. Two terminal options: B‑flat bolted / K‑hook‑fork customized.
Need a Fuse for Your Project?
Share your requirements with us for product guidance and a quotation.
Dimensions (mm)
Din xxxU-74ES Dimensions
Bolted xxxB-74ES Dimensions
Customize xxxU-74ES Dimensions
GFHVT1500‑74ES Series Square‑Body Fast‑Acting aR DC Fuse 1500VDC 100‑800A
GFHVT1500‑74ES Series Square‑Body Fast‑Acting aR DC Fuse 1500VDC 100‑800A is Size 3# square‑body bolt‑mount aR‑class high‑speed DC fuse for high‑voltage new‑energy DC‑system applications. Rated voltage 1500VDC, max breaking capacity 50kA@1500VDC (Time Constant ≤5ms), minimum breaking current ≥5In. Two mechanical terminal configurations are available: B‑type flat bolted horizontal connection; K‑type customized hook‑fork vertical connection. It features excellent cycling performance, low power loss, strong anti‑arc capability and wide ambient‑temperature adaptability, mechanical shock‑vibration resistance ≥20g. Performance references UL‑248‑1/UL‑248‑13, IEC 60269‑1/IEC 60269‑4, RoHS compliant; REACH document is available upon request. It provides dependable short‑circuit protection for energy‑storage cabinets, lithium‑ion battery‑packs, safety disconnect switches and DC relay backup units.
GFHVT1500-74ES-Series.-100-800A-1500Vdc-IR.50kA-fast-acting-fuse-1
Key Features
- Model Series: GFHVT1500‑74ES Square‑Body Fast‑Acting aR DC Fuse
- Rated Voltage: 1500 VDC
- Current Range: 100A‑800A; Operation Class: aR (semiconductor short‑circuit protection)
- Max Breaking Capacity: 50kA @1500VDC (Time Constant ≤5ms)
- Minimum Breaking Current: ≥5 In
- Two interchangeable terminals: B‑flat bolted horizontal; K‑custom hook‑fork vertical
- Outstanding cycling capability & low watt‑loss characteristic
- Ultra‑fast fault‑current interruption, strong anti‑voltaic impingement
- Size 3# square‑body package for high‑voltage cabinet layout optimization
- High shock‑vibration resistance ≥20g, suitable for industrial & energy‑storage cabinet environment
- Compliance: Referenced to UL‑248‑1/UL‑248‑13, IEC 60269‑1/IEC 60269‑4, RoHS; REACH on request
General Technical Specifications
| Product Series | GFHVT1500‑74ES Series Square‑Body Fast‑Acting aR DC Fuse |
| Rated Voltage | 1500 V DC |
| Rated Current Range | 100A‑800A (aR operation class) |
| Max Breaking Capacity | 50kA @1500VDC (Time Constant ≤5ms) |
| Minimum Breaking Current | ≥5 In |
| Body Size | Size 3# square‑body |
| Terminal Options | B‑flat bolted horizontal / K‑hook‑fork customized vertical |
| Shock & Vibration Resistance | ≥20g |
| Standards Compliance | Referenced to UL‑248‑1/UL‑248‑13, IEC 60269‑1/IEC 60269‑4, RoHS |
| Operating Temperature | ‑5℃ ~ +40℃(nominal);‑40℃~+85℃(allowable) |
| Storage Temperature | ‑40℃ ~ +120℃ |
Part Number List & Electrical Parameters(Test@1500VDC,50kA,Time‑Constant≤5ms)
| Part Number | Rated Current | Terminal Type | Pre‑Arcing I²t (A²s) | Clearing I²t (A²s) | Power Loss(W) @1.0In | Body Size |
| GFHVT1500‑100B‑74ES | 100A | B‑bolted | 3090 | 22480 | 62 | 3# |
| GFHVT1500‑125B‑74ES | 125A | B‑bolted | 5430 | 33650 | 70 | 3# |
| GFHVT1500‑160B‑74ES | 160A | B‑bolted | 8760 | 54250 | 81 | 3# |
| GFHVT1500‑200B‑74ES | 200A | B‑bolted | 13980 | 86450 | 92 | 3# |
| GFHVT1500‑250B‑74ES | 250A | B‑bolted | 22150 | 136850 | 103 | 3# |
| GFHVT1500‑315B‑74ES | 315A | B‑bolted | 35850 | 221450 | 118 | 3# |
| GFHVT1500‑400B‑74ES | 400A | B‑bolted | 57650 | 354650 | 134 | 3# |
| GFHVT1500‑500B‑74ES | 500A | B‑bolted | 94250 | 579050 | 152 | 3# |
| GFHVT1500‑630B‑74ES | 630A | B‑bolted | 153050 | 945050 | 173 | 3# |
| GFHVT1500‑700B‑74ES | 700A | B‑bolted | 182520 | 1123800 | 196 | 3# |
| *GFHVT1500‑800B‑74ES | 800A | B‑bolted | 283420 | 1656050 | 219 | 3# |
| GFHVT1500‑100K‑74ES | 100A | K‑hook‑fork | 3090 | 22480 | 62 | 3# |
| GFHVT1500‑125K‑74ES | 125A | K‑hook‑fork | 5430 | 33650 | 70 | 3# |
| GFHVT1500‑160K‑74ES | 160A | K‑hook‑fork | 8760 | 54250 | 81 | 3# |
| GFHVT1500‑200K‑74ES | 200A | K‑hook‑fork | 13980 | 86450 | 92 | 3# |
| GFHVT1500‑250K‑74ES | 250A | K‑hook‑fork | 22150 | 136850 | 103 | 3# |
| GFHVT1500‑315K‑74ES | 315A | K‑hook‑fork | 35850 | 221450 | 118 | 3# |
| GFHVT1500‑400K‑74ES | 400A | K‑hook‑fork | 57650 | 354650 | 134 | 3# |
| GFHVT1500‑500K‑74ES | 500A | K‑hook‑fork | 94250 | 579050 | 152 | 3# |
| GFHVT1500‑630K‑74ES | 630A | K‑hook‑fork | 153050 | 945050 | 173 | 3# |
| GFHVT1500‑700K‑74ES | 700A | K‑hook‑fork | 182520 | 1123800 | 196 | 3# |
| *GFHVT1500‑800K‑74ES | 800A | K‑hook‑fork | 283420 | 1656050 | 219 | 3# |
Application Scenarios
GFHVT1500‑74ES Series Square‑Body Fast‑Acting aR DC Fuse 1500VDC 100‑800A is designed for high‑voltage DC new‑energy projects. Suitable for large‑capacity energy‑storage power‑station cabinets, lithium‑ion battery‑pack protection, maintenance safety disconnect switches and DC relay backup short‑circuit protection. aR‑class fast‑acting performance delivers reliable fault‑current protection for power semiconductors and high‑voltage DC‑side power components.
Installation & Operating Notes
- Size 3# square‑body construction; select B‑flat bolted or K‑hook‑fork terminal according to cabinet layout. Apply proper bolt torque to prevent bad contact and over‑heating.
- Recommended continuous working current ≤75% of fuse rated‑current. Apply temperature‑derating factor Kt when ambient temperature exceeds +40℃.
- Altitude ≤2000m: no‑derating; closed‑box installation 2000‑4500m: derate 2%‑5% per 1000m elevation. Re‑check insulation clearance per GB/T16935.1 for high‑altitude deployment under 1500VDC high‑voltage condition.
- Permits vertical, horizontal, inclined mounting. Avoid gravity‑vibration negative influence over electrical contact performance.
- Forced‑air cooling improves heat dissipation and allowable operating current, refer to Kv correction coefficient.
- Never replace fuse under live DC load unless equipped with certified load‑break switchgear, strictly follow 1500VDC high‑voltage safety operation procedure.
- Replace fuse immediately if shell crack, deformation or mechanical damage appears.
- Additional reliability validation test required for extremely high‑vibration industrial environments.
- Select matched copper conductor cross‑section for terminals to control temperature‑rise performance for high‑voltage heavy‑current working condition.
- Ordering reminder: specify terminal type B(flat bolted) or K(hook‑fork customized) when placing purchase order; models marked asterisk * need factory pre‑confirmation before order placement, electrical performance is identical for two terminal versions.
Packing & Storage Requirements
Standard original‑box bulk package. Store in clean, dust‑free warehouse. Storage temperature:‑40℃~+120℃; humidity limit: RH≤70%@40℃, RH≤80%@30℃, RH≤90%@20℃. Sample testing support, OEM customization, stable mass‑volume supply for energy‑storage and new‑energy equipment manufacturers. REACH declaration available upon customer request.
Preguntas frecuentes
Q: What rating for GFHVT1500‑74ES Series Square‑Body Fast‑Acting aR DC Fuse 1500VDC 100‑800A?
A: Rated 1500VDC, current range 100‑800A, aR fast‑acting class, max breaking capacity 50kA@1500VDC(Time Constant ≤5ms), minimum breaking current ≥5In, Size 3# square‑body.
Q: Difference between B‑type and K‑type terminals?
A: B‑type is flat bolted horizontal connection; K‑type is customized hook‑fork vertical terminal. Both versions share exactly same electrical parameters, only mechanical mounting differs, specify terminal model on purchase order.
Q: What body size for GFHVT1500‑74ES?
A: Size 3# square‑body construction, two optional terminal structures B / K.
Q: What standards does GFHVT1500‑74ES comply with?
A: Performance referenced to UL‑248‑1/UL‑248‑13, IEC60269‑1/IEC 60269‑4, RoHS compliant; REACH document available on request.
Q: Main application scenarios for GFHVT1500‑74ES?
A: Energy‑storage cabinets, maintenance safety disconnect switches, lithium‑ion battery‑pack and DC relay backup short‑circuit protection.
