GFEVF300 North American Style aR Semiconductor DC Fuse 250-300VDC 35-2500A
GFEVF300 North American Style aR Semiconductor DC Fuse 250-300VDC 35-2500A is north-american standard high-speed semiconductor DC power fuse. Operation class aR for semiconductor device short-circuit protection. Rated 250‑300VDC, max 50kA breaking capacity, low arc‑voltage and low let‑through I²t value. Supports parallel connection for higher ampacity. Complies with UL‑248, IEC 60269‑4, CE and RoHS. Widely used for battery pack, DC drives, power converters, rectifiers and DC relay backup protection.</p>
connection for higher ampacity. Complies with UL‑248‑13, IEC 60269‑4, CE and RoHS. Widely used for battery pack, DC drives, power converters, rectifiers and DC relay backup protection.
Key Features
- Model Series: GFEVF300 north‑american style semiconductor DC power fuse
- Rated Voltage: 250‑300 VDC
- Current Range: 35A‑2500A, Operation Class: aR
- Max Breaking Capacity: 50kA @300VDC
- Time Constant: 2.5±0.5 ms
- Low arc‑voltage, low energy let‑through I²t characteristics
- Low watt losses, superior cycling capability
- Parallel installation permitted for higher ampacity within dimensional limits
- High mechanical shock & vibration resistance ≥20g
- Compliant: UL‑248‑13, IEC 60269‑4, CE, RoHS; REACH available upon request
General Technical Specifications
| Product Series | GFEVF300‑Series North‑American Style Semiconductor DC Power Fuse |
| Rated Voltage | 250‑300 V DC |
| Rated Current Range | 35A‑2500A (aR operation class) |
| Max Breaking Capacity | 50kA @300VDC |
| Time Constant | 2.5±0.5 ms |
| Vibration Resistance | ≥20g |
| Standards Compliance | UL‑248‑13, IEC60269‑4, CE, RoHS |
| Operating Temperature | ‑5℃ ~ +40℃(regular);‑40℃~+85℃(allowable) |
Part Number List & Electrical Parameters
| Rated Current | Pre‑arc A²s | Clearing A²t | Power Loss(W) |
| 35A | 50 | 230 | 4.2 |
| 40A | 60 | 310 | 5.2 |
| 45A | 80 | 390 | 5.7 |
| 50A | 100 | 520 | 6.0 |
| 60A | 140 | 740 | 8.1 |
| 70A | 330 | 1400 | 7.2 |
| 80A | 430 | 1850 | 8.1 |
| 90A | 570 | 2450 | 9.0 |
| 100A | 740 | 3150 | 10.0 |
| 125A | 1130 | 4850 | 12.5 |
| 150A | 1620 | 6950 | 15.5 |
| 175A | 2170 | 9300 | 18.5 |
| 200A | 2790 | 12000 | 22 |
| 225A | 3210 | 14700 | 24 |
| 250A | 3960 | 18100 | 27 |
| 275A | 4720 | 21600 | 31 |
| 300A | 6000 | 27300 | 32 |
| 350A | 10600 | 48600 | 39 |
| 400A | 14500 | 66100 | 44 |
| 450A | 22100 | 101000 | 49 |
| 500A | 28000 | 128000 | 54 |
| 600A | 41100 | 188000 | 62 |
| 700A | 48800 | 190000 | 72 |
| 800A | 59000 | 230000 | 84 |
| 1000A | 94000 | 360000 | 100 |
| 1200A | 922000 | 750000 | 103 |
| 1500A | 120000 | 880000 | 140 |
| 1600A | 160000 | 1200000 | 140 |
| 2000A | 320000 | 2300000 | 151 |
| 2500A | 670000 | 4700000 | 163 |
Application Scenarios
GFEVF300‑series north‑american style semiconductor dc power fuse 300VDC 35‑2500A aR class is designed for semiconductor‑related DC‑system protection: energy‑storage battery‑pack, DC drives, power converters, rectifier equipment and DC relay backup protection. aR‑class high‑speed characteristic provides reliable short‑circuit protection for power semiconductors under heavy‑fault‑current conditions.
Installation & Operating Notes
- Bolt‑on mounting type; apply proper bolt torque to avoid poor contact and over‑heating risk.
- Recommended continuous operating current ≤75% of fuse rated‑current; apply temperature‑derating factor for ambient temperature over 40℃.
- For closed‑box / high‑altitude installation (>2000m), perform rated‑current derating in accordance with datasheet requirements.
- Parallel mounting is allowed only within dimensional and specification guidelines for higher ampacity.
- Do NOT replace fuse under live DC load unless equipped with certified load‑break switchgear.
- Replace fuse immediately if mechanical damage, crack or deformation occurs on fuse body.
- Additional reliability validation test shall be conducted for extremely high‑vibration working environments.
Packing & Supply
Standard bulk package. Sample testing support, OEM customization, stable mass‑volume supply for energy‑storage, power‑converter and new‑energy equipment manufacturers. REACH declaration available upon customer request.
अक्सर पूछे जाने वाले प्रश्न
Q: What rating for GFEVF300‑series north‑american style semiconductor dc power fuse 300VDC 35‑2500A aR class?
A: Rated 250‑300VDC, current range 35‑2500A, aR semiconductor‑protection class, max breaking capacity up to 50kA@300VDC.
Q: What is aR‑class operation for this fuse?
A: aR class is semiconductor‑protecting high‑speed fuse class, designed for fast short‑circuit protection of power semiconductor devices.
Q: What standards does GFEVF300‑series comply with?
A: UL‑248‑13, IEC60269‑4, CE, RoHS compliant; REACH document available on request.
Q: Main application scenarios for GFEVF300‑series?
A: Energy‑storage battery‑pack, DC drives, power converters, rectifiers and DC relay backup semiconductor short‑circuit protection.
